Target power supply of 3.3 V maximum 120 mA, 5 V maximum 500 mA, depending on the PC.

Adaptive bit-rate adjustment automatically detects SPI bit rates that are set too high.

Very fast programming cycle thanks to onboard processor and sophisticated firmware.

Four different operating modes: AVR, STM, NXP/LPC and USB serial converter up to 1 Mbit.

All NXP/LPC Cortex-M controllers with UART bootloader.

All STM32 Cortex-M controllers with UART bootloader.

All other AVR controllers that support the SPI programming interface.

Bascom with setting options->Programmer = STK500: C:\Programs\Atmel\AVR Tools\STK500\stk500.exe and installed AVR Studio.

Two integrated status LEDs indicate the current status of the Electronics and housing are made entirely in Germany. This helping hand for professionals, hobbyists and ambitious novices is delivered in an original laser-cut Plexiglas® housing. This voltage can be set to 5 V or 3.3 V and can be switched on or off. Target voltage supply is also possible via the DIL switch. NEW for AVR mode! The adaptive bit-rate adjustment automatically detects and adjusts SPI bit rates that are set too high. As a special treat, a fourth mode-which emulates a USB-to-serial converter-is included. A DIP switch can be used to select between Atmel AVR, STM32 and NXP/LPC. The Atmel AVR controllers and ST and NXP Cortex-M controllers can be programmed via the ISP interface and UART bootloader respectively. Three different programming modes allow it to be used in a variety of applications.

PROG-S for Atmel AVR, STM32, NXP and LPC controllersĪ real all-rounder.
